For testing surface energy.
To determine the cleanliness of surfaces.
Test Inks can make statements on the adhesive strength of printing inks, coatings and adhesives on all surfaces such as plastic, metal and glass as well as on the degree of cleanliness in mN/m (dyne/cm).
For more information, please visit us at:
www.arcotest.infoOur offer is aimed exclusively at traders.
All prices are exclusive of of statutory VAT.
arcotest® ORGANIC Test Inks
30 to 60 mN/m surface tension
In bottles, pen format, or disposable wipes
ORGANIC test inks do not require hazard labeling.
observation time: 2 sec.
arcotest® Test Pens PINK
22 bis 60 mN/m Oberflächenspannung
In bottles or in pen form
observation time: 2 to 4 sec.
.
Test Inks arcotest® BLUE
18 to 105 mN/m surface tension
Available in bottles or in pen form (28 to 72 mN/m).
Toxic from 24 to 57 mN/m.
observation time: 2 sec.
New
RAPIDTEST 38® Jumbo refillable
Our RAPIDTEST 38® makes it easy to test the surface energy of pre-treated plastics.
The RAPIDTEST 38® enables very precise testing of the surface energy after pre-treatment of plastics such as PP and PE. The RAPIDTEST 38® test ink is suitable for corona, plasma and flame testing. A treatment can be recognised immediately by a closed colour stroke; necessary corrections to the pre-treatment can be deduced from the beading of the test ink.
The RAPIDTEST 38® is a particularly easy-to-use test device that has proven itself in daily use by manufacturers of films and moulded parts.
• easy to handle
• perfect for quick checks on polyolefins
• Smudge-proof and waterproof
• Colour-intensive, low-odour ink
• Ink colour: green
• The permanent display of the test result can be stored for quality assurance purposes
arcospray® 38
The arcospray® 38 test ink is a test liquid with a surface tension of 38 mN/m. It has been designed to quickly detect whether the surface is grease-free, as values equal or greater than that mean freedom from grease.
After its application, arcospray® 38 can be removed without residue using oil-free clean blower air (compressed air). Tested parts can be used further. arcospray 38 makes it possible to quickly and easily assess large and small surfaces, such as chain links, alike.
• Optimal for very small and large areas
• Easy to use
• Not toxic
• Not harmful to health
• Not harmful to the environment
• residue-free testing of surfaces
• Simply spray on the arcospray ink
• result visible within 2 seconds
• Test non-contact surfaces
38 mN/m • 38 dyne/cm
with accuracy: +/- 1,0 mN/m
Available:
100 ml spray bottle
arcotest® ORGANIC Test Inks
arcotest® ORGANIC test inks are green test fluids with a defined surface tension. They have been specially developed to provide non-toxic, non-hazardous-labelled inks. The application and handling of arcotest® ORGANIC are based on DIN 53364 and ISO 8296.
ORGANIC Test Inks are label-free according to the Ordinance on Hazardous Substances (EU) No. 1272/2008 (CLP).
The arcotest® ORGANIC Test Inks are available in bottles or in pens.
A notice:
Test pens should not be used if the surface is contaminated, as residual contamination from the test surface can remain in the felt of the pens and falsify later values.
Verwenden Sie bei verunreinigten Oberflächen
• Testing in bottles with arcotest® cotton swabs
• arcoweb
ORGANIC in bottles
30 to 60 mN/m
with accuracy: +/- 0,5 mN/m
Available:
in bottles of 10, 100 or 250 ml
or in sets of 7 bottles of 10 ml
Test Pens arcotest® ORGANIC
30 to 60 mN/m
with accuracy: +/- 1,0 mN/m
Available:
in sets of 4, 6, and 8
or as single pens, 5 ml
arcotest® ORGANIC Jumbo
30 to 46 mN/m
with accuracy: +/- 1,0 mN/m
Available:
in sets of 4, 6, and 8
or as single pens, 17 ml
arcoweb® tissues
38 mN/m
with accuracy: +/- 1,0 mN/m
Available:
in individual packaging
arcotest® Test Pens PINK
arcotest® PINK test inks are test fluids with a defined surface tension and a pink colour. They have been specially developed to offer non-toxic test inks. These PINK test inks can be used as an alternative to the BLUE test inks, as their application and handling are based on DIN 53364 and ISO 8296.
The PINK Test Inks are available in bottles or in pens.
Non-toxic.
observation time:
from 22 to 26 mN/m : 2 sec.
from 28 to 44 mN/m : 4 sec.
from 45 to 60 mN/m : 2 sec.
from 28 to 44 mN/m : 4 sec.
from 45 to 60 mN/m : 2 sec.
Test Inks PINK in bottles
22 to 60 mN/m
with accuracy: +/- 0,5 mN/m
Available:
in bottles of 10, 100 or 250 ml
or in sets of 7 bottles of 10 ml
Test Pens PINK
22 to 60 mN/m
with accuracy: +/- 1,0 mN/m
Available:
in sets of 4, 6, and 8
or as single pens, 5 ml
Test Pens arcotest® PINK Jumbo
30 to 50 mN/m
with accuracy: +/- 1,0 mN/m
Available:
in sets of 4, 6, and 8
or as single pens, 17 ml
Test Inks arcotest® BLUE
arcotest® BLUE test inks are liquids (in accordance with ISO 8296 / DIN 53364) with a defined surface tension and blue colour. The surface tension of the material being tested is determined by simply applying the test inks to the surface.
The BLUE Test Inks are available in a range from 18.4 to 105 mN/m.
Available in bottles or in pen form (28 to 72 mN/m).
Toxic from 24 to 57 mN/m.
observation time: 2 sec.
Test Pens BLUE
from 28 – 60 mN/min steps of one by one
from 62 – 72 mN/m in steps of two by two
with accuracy: +/- 1,0 mN/m
Available:
in sets of 4, 6, and 8
or as single pens, 5 ml
Test Inks BLUE in bottles
18,4 to 105 mN/m
with accuracy: +/- 0,5 mN/m
Available:
in bottles of 10, 100 or 250 ml
or in sets of 7 bottles of 10 ml
RAPIDTEST 38®
RAPIDTEST 38® Jumbo
38 mN/m approx.
RAPIDTEST 38® serves to check if the treatment of polyolefins has shown an effect.
- extremely easy to handle
- perfect for quick checks
- no wiping off necessary
- lasting display of result
- archiving of test result possible
QUICKTEST 38®
38 mN/m approx.
QUICKTEST 38® serves to check if the treatment of polyolefins has shown an effect.
- good readability due to striking red colour
- extremely easy to handle
- perfect for quick checks
- no wiping off necessary
- lasting display of result
- archiving of test result possible
RAPIDTEST 38® Jumbo
QUICKTEST 38® Jumbo
better colour presentation
line thickness: 15 mm
contents: 15 ml
optimal for testing large film
Service
Expert advice, guaranteed specified values, reliable and prompt delivery, and cooperation with our customers at home and abroad have been our top priorities for 50 years.
Quality control
For quality assurance, the inks are tested using a state-of-the-art contact angle measuring device, taking temperature and density into account.
Safety data sheets provide information on handling, storage and transport regulations.
Purchase orders B2B
here in the online shop after registration.
Inquiries, offers Inquiries and orders in writing by post, fax, e-mail or via the contact form.
